Fully loosen the jam nuts (1 and 2) and mount the cable housing to the frame.
Make sure the throttle pedal is against the rear pedal stop (3).
Pull the throttle cable housing toward the rear of the kart until you feel resistance.
Warning: DO NOT pull the throttle cable housing any further.
Hold the cable housing in this position and screw the front jam nut (2) against the frame.
Warning: Pulling the housing past the first point of resistance will engage the engine throttle while the throttle pedal is in the idle position. Upon starting the engine, the vehicle may accelerate.
Screw the rear jam nut (1) against the frame. Tighten the front jam nut (2) securely.
Make sure the engine throttle linkage is in the idle position and the throttle pedal is against the rear stop.
Block the rear end of the kart up off the ground and start the engine. If the engine is not at idle speed, stop the engine and repeat the above procedures.
Warning: The engine must be at idle speed when the throttle pedal is in the rear position. Failure to adjust the throttle properly may result in personal injury and/or vehicle damage. If you are unable to properly adjust the throttle, contact a dealer for assistance.
Make sure the exposed end of the throttle cable does not interfere with throttle mechanism and the cable end does not come in contact with engine ground terminal.
Inspection:
The throttle cable housing may need to be adjusted periodically because the cable stretches. When fully depressing the throttle pedal no longer activates full engine speed, adjust the throttle cable housing.
|
|
|
|
|
|
|
Pass the throttle cable through the cable retainer and butt the throttle cable housing end against the inside shoulder of the cable retainer.
The cable retainer is to be securely fastened to the engine with the clamping screw.
Pass the end of the cable through the hole in the cable stop.
Before tightening the cable stop screw ...
Ensure the spring anchor, spring & cable are installed as illustrated.
Ensure the throttle pedal is in the rearward (idle) position.
Ensure there's no slack in the cable with no tension applied to the return spring.
Ensure the housing is inside and against the cable retainer.
Note: The part numbers on the illustration above were used by Manco, these are not Briggs and Stratton part numbers.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
